Introducing...

HEATPOWER 300 MARINE

Next-gen waste heat recovery technology for a new era of sustainable shipping.

Reduce CO2 emissions, generate clean on-board energy and cut fuel comsumption with HeatPower.

device

THE LATEST IN MARITIME
WASTE HEAT RECOVERY TECHNOLOGY

Developed by marine engineers exclusively for the shippping industry, HeatPower 300 Marine is built to withstand tough at-sea environments. Delivering enhanced seaworthiness, optimal performance and increased energy outputs, HeatPower 300 Marine improves on-board energy efficiency and transforms a hazardous byproduct into clean, renewable electricity.

icon

Generate up to 1MW of clean, on-board electricity
with Climeon HeatPower 300 Marine systems

image 9

Cut fuel consumption
up to 5%

image 4

Improve energy efficiency

hp300
1 1

Reduce CO2 emissions

image 4 (1)

Enhance EEDI, EEXI
and CII ratings

TECHNICAL DATA

Net power output

50 – 355 kW

Thermal power absorbed

1000 – 4000 kW

Hot water temperature

Min 80 °C

Cold water temperature

0 – 35 °C

Working media

Environmentally friendly, non-toxic, non-flammable

Target engine size

>15 MW

Dimensions

L x W x H = 5.8 x 2.4 x 2.8 m

Weight, dry (operation)

13000 kg (14 700 kg)

Mains connection

380-480, 690 VAC, 50/60 Hz

Control system

PLC system / MODBUS TCP

Integration points

Hot side: Jacket cooling water/ HT/WHR circuit,
Cold side: Sea water
Other: Instrument air, Ship grid, Ship IAS/CAMS

WHY CHOOSE CLIMEON HEATPOWER 300 MARINE SYSTEMS?

Designed for low-carbon shipping, HeatPower 300 Marine has been developed exclusively for the maritime industry. Building on the success of our original HP150 module, HeatPower 300 Marine systems enable larger vessels to increase energy efficiency and sustainability.
Learn more about our tech and find out why HeatPower 300 Marine is the optimal choice for your fleet:

WORLD-LEADING LOW-TEMP CONVERSION EFFICIENCY

Capable of generating up to 1MW of onboard energy from low-temp waste heat, Climeon HeatPower Marine systems outperform competing maritime ORC systems to offer maximum performance, energy outputs and emissions reductions.



SAFETY-FIRST DESIGN



Climeon’s HeatPower technology meets and exceeds the sector's stringent safety requirements, including SOLAS, and uses non-toxic, non-flammable working media to convert onboard waste heat safely and efficiently.

MODULAR AND SCALABLE

Install up to three HeatPower 300 Marine modules to utilize onboard thermal energy and maximize energy outputs. Customizable integration options ensure seamless functionality and performance on any vessel.

NEW-BUILD AND RETROFIT APPLICATION

Achieve enhanced EEDI or EEXI ratings with HeatPower 300 Marine.
New-build and retrofit applications ensure you can decarbonize your entire fleet with our waste heat recovery technology.

DIRECT SEAWATER COLD SOURCE

WHR systems require a hot source (waste heat) and cold source. While most systems cannot withstand the impact of fresh seatwater, our corrosion-resistant titanium heat exchanger ensures seawater can provide an unlimited direct cold source for your system.

SIMPLE INSTALLATION

Each HeatPower 300 Marine module is delivered on a self-contained skid for a simple and straightforward installation process. With just five external inputs, decarbonizing your fleet has never been easier.

AUTOMATED MONITORING
AND MANAGEMENT

The Climeon HeatPower Control system monitors and manages onboard electricity production for optimal performance, while the optional cloud-based Climeon Live system provides ship-to-shore data collection, real-time analysis, and finetunes running parameters for maximum energy output.

FUTUREPROOF MARITIME
ORC TECHNOLOGY

Built to last for a vessel’s entire 25-year lifetime, HeatPower is designed for the future. With optional enhancements to boost power outputs and enhance emissions reductions, HeatPower 300 Marine
meets the needs of an evolving industry.

REDUCED PAYBACK TIMES

Increased energy outputs and less fuel usage deliver both environmental and financial savings. With reduced payback times, integrating HeatPower 300 Marine is a cost-effective way to optimize performance and decarbonize your fleet.

DOWNLOAD FREE WHITE PAPER

Learn more about maritime ORC waste heat recovery and discover how HeatPower increases energy efficiency, reduces emissions and cuts fuel consumption.

HeatPower300_SmalCover-_00003 1 (1)

DECARBONIZE YOUR FLEET

WITH CLIMEON HEATPOWER MARINE SYSTEMS

Find out how our maritime ORC systems can transform
the energy efficiency of your vessels.
